Ajax NVR (8-ch)
Product Description
NVR is a network video recorder for home and office video surveillance. You can connect third-party IP cameras to the device.
The user can watch archived and online videos in Ajax apps. NVR records the received data with corresponding settings and a hard drive (not included). If the hard drive is not installed, the video recorder is used only for integrating third-party IP cameras into the Ajax system. NVR provides users with video alarm verification.
More features
Operating principle
NVR is a video recorder for connecting third-party IP cameras with ONVIF and RTSP protocols. It allows you to install a storage device with a memory capacity of up to 16 TB (not included in the NVR package). NVR also works without a hard disk.
Selecting the location of the device
NVR is designed for indoor installation. We recommend installing the video recorder on a flat horizontal or vertical surface for better heat exchange of the hard disk. Do not cover it with other objects.
The device is equipped with tamper protection. The tamper protection reacts to attempts to break or open the housing cover and notifies you of this via the Ajax apps.
A device without a hidden agenda
All data is stored securely within the European Union and fully complies with European data protection standards.
Ajax NVR is NDAA compliant and every component is sourced from manufacturers trusted and approved by the U.S. government. It is versatile and can be installed in any location. In addition, Ajax NVR has undergone independent cybersecurity testing to ensure safety and reliability.
Specifications
| Compatibility |
Control panels Hub Hub Plus Hub 2 (2G) Hub 2 (4G) Hub 2 Plus Hub Hybrid (2G) Hub Hybrid (4G) |
| Video stream |
NVR models 8 channels With a resolution of up to 4K (25/30 FPS). IP cameras ONVIF (Profile S/T) RTSP Storage hard disk with a capacity of up to 16 TB (SATA connection, format 3.5") HDD not included. Decoding formats H.265 H.264 Bandwidth up to 100 Mbps |
| Recommendations | The operating voltage of the device is 110-240 V~. NVR is designed for indoor installation only. |
| Communication channels |
Ethernet up to 100 Mbps Bluetooth BLE frequency band: 2.400-2.4835 GHz To set up an Ethernet connection. Power of the radio signal 2.5 mW (limit of maximum 100 mW) |
| Main features |
Motion detection NVR has built-in software to detect the motion in the frame. Possibility to switch between image analysis with the NVR or camera algorithms. In-app video management system Video wall that combines images from all connected cameras. Event filters. Timeline with a smooth preview. Visual verification of Ajax alarms With NVR you can set up a scenario where the Ajax detectors trigger specific cameras for video recording. This gives immediate results in the mobile and desktop (monitoring) apps. Privacy Distribution of access rights for users in mobile apps and for monitoring operators in PRO Desktop. |
| Power supply |
Head 110-240 V~, 50/60 Hz, 0.6 A Up to 24 W of mains power consumption. Reserve CR2032 battery, 3V Only to power the system clock. |
| Anti-sabotage protection |
Sabotage alarm Warnings of attempts to loosen the detector from the surface or to remove the detector from the mounting panel. |
| Housing |
Dimensions 193 × 193 × 47 mm Weight 700 g Without a hard drive. Operating temperature range from 0°C to +40°C Operating humidity up to 75% Protection class IP20 |
| To colour | White, Black |
| Full set | • NVR • SmartBracket mounting panel • Power cord • Ethernet cable • Installation kit • Quick Start Guide |
