Milesight 8MP AI IR Mini Dome Camera (MS-C8183-PC)
Product description
The Milesight MS-C8183-PC is a professional dome camera from the Milesight AI series, designed for reliable indoor security. Its impressive 8MP resolution captures exceptionally sharp images, while the fixed 2.8 mm lens provides a wide 110° field of view.
Thanks to its excellent low-light performance and integrated night vision up to 20 meters, the surroundings remain clearly visible even in low light or complete darkness.
More features
8MP Ultra HD with a wide field of view
The 8MP sensor delivers detailed images at a maximum resolution of 3840 × 2160 pixels. The fixed 2.8 mm lens provides a wide field of view of approximately 110°, allowing a large area to be monitored with a single camera.
Ideal for offices, shops, entrances, corridors and other indoor spaces where a wide overview is desired.
Excellent image quality in low light
The MS-C8183-PC is designed for situations where available lighting is limited. The camera maintains clear images in low light and switches to integrated IR illumination in complete darkness.
With a night vision range of up to 20 meters, the camera provides reliable monitoring day and night.
Flexible storage
Footage can easily be recorded to an NVR, but the camera can also be used completely standalone thanks to support for microSD storage.
This makes the MS-C8183-PC suitable for both standalone camera applications and professional security systems.
Compact AI dome design
The compact dome design makes the camera discreet and versatile. As part of the Milesight AI series, the MS-C8183-PC also offers intelligent video analytics, providing more than traditional video surveillance alone.
Specifications
| Model | MS-C8183-PC |
| Camera | |
| Name | AI IR Mini Dome Network Camera |
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.012Lux @F1.6 B/W: 0Lux with IR on |
| WDR | 120dB Super WDR |
| Lens | 2.8mm @F1.6 |
| Mount | M12 |
| Field of View | H110°/D126°/V60° |
| Shutter Time | 1/100000s∼1s |
| Day/Night Mode |
Day/Night/Auto/Customize/ Schedule |
| IR Distance | Up to 20m |
| S/N | >55dB |
| Video | |
| Max. Image Resolution | 3840x2160 |
| Primary Stream | 60Hz/50Hz: 30fps@(3840x2160, 3072x2048, 2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576) |
| Secondary Stream |
60Hz: 30fps@(704x576, 640x480, 640x360, 352x288) 50Hz: 25fps@(704x576, 640x480, 640x360, 352x288) |
| Tertiary Stream |
60Hz: 30fps@(1280x720, 704x576, 640x480, 640x360, 352x288) 50Hz: 25fps@(1280x720, 704x576, 640x480, 640x360, 352x288) |
| Video Compression |
H.265+/H.265(HEVC)/H.264+/ H.264/MJPEG |
| Video Bit Rate | 16Kbps∼16Mbps (CBR/VBR adjustable) |
| Privacy Masking | Up to 28 areas (24 mask areas and 4 mosaic areas) |
| ROI | Up to 8 areas |
| Image Settings |
Saturation/Brightness/Contrast/ Sharpness |
| Interface | |
| Ethernet | 1*RJ45 10M/100M Ethernet Port |
| Audio Interface | Built-in Microphone |
| Network | |
| Network Storage | NAS(Support NFS, SMB/CIFS), ANR |
| Network Protocols | IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, Bonjour, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL |
| Audio | |
| Audio Compression | G.711/AAC/G.722/G.726 |
| Audio Sampling Rate | 8/16/32/48KHz |
| Audio Bit Rate | 16~256kbps |
| Built-in Microphone | Support |
| Intelligent Analytics | |
| Video Analysis | Region Entrance, Region Exiting, Advanced Motion Detectionn, Line Crossing, Loitering, Object Left, Object Removed |
| Face Detection | Detect and capture faces, get real-time snapshots |
| People Counting & Report | Count the number of people entering or exiting |
| System | |
| Storage | Support microSD/SDHC/SDXC Card Local Storage, up to 256TB |
| Advanced Function | Heat Map, BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, EIS, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark |
| SIP/VoIP Support | Yes, Voice&Video-over-IP |
| Event Trigger | Motion Detection, Network Disconnection, Audio Alarm, etc |
| Event Action | FTP Upload, SMTP Upload, SD Card Record, SIP Phone, HTTP Notification, etc. |
| System Compatibility | ONVIF Profile G & Q & S & MT API |
| General | |
| Working Temperature | -40℃∼60℃ |
| Working Humidity | 0∼90% (Non-condensing) |
| Power Supply | PoE(802.3af) |
| Power Consumption | 5W MAX, 7W MAX (With IR on) |
| Weight | 200g |
| Dimensions | Φ97.8mmX57.9mm |
