Milesight 8MP AI Motorized Bullet Camera (MS-C8164-FIPE)
Product Description
The Milesight MS-C8164-FIPE is an advanced 8 MP 4K bullet network camera for professional indoor and outdoor security. Thanks to the motorized varifocal lens, powerful AI features, and PoE support, this camera offers a flexible and reliable solution for applications such as public safety, access control, corporate sites, and commercial use.
More features
8 MP 4K image quality and motorized varifocal lens
With its 8 MP sensor, the Milesight MS-C8164-FIPE delivers razor-sharp 4K Ultra HD images with high levels of detail. The motorized varifocal lens makes it possible to precisely adjust the field of view to the desired situation. This makes the camera suitable for both wide-angle overviews and focused monitoring of specific zones.
The improved WDR (Wide Dynamic Range) technology also ensures a clearer image in challenging lighting conditions, for example, when a scene contains both very bright and dark areas. With ROI (Region of Interest), important parts of the camera image can receive extra attention without unnecessarily consuming high bandwidth.
Advanced AI security
The built-in artificial intelligence (AI) makes the Milesight MS-C8164-FIPE suitable for intelligent video surveillance. Advanced AI algorithms help analyze camera images and support more efficient detection and security processes.
Furthermore, the camera features extensive heatmap functionality, which allows activity and movement within a monitored area to be visualized. This is valuable for applications such as visitor analysis, access control, and the optimization of business processes.
Robust design for indoor and outdoor use
The Milesight MS-C8164-FIPE is designed for long-term use in a wide variety of conditions. Thanks to its IP67 rating, the camera is protected against dust and water, making it suitable for outdoor use. The IK10 rating also provides a high level of protection against vandalism and mechanical impact.
This makes this 4K security camera a suitable choice for premises such as office buildings, parking lots, access roads, public spaces, and other locations where reliability and durability are important.
PoE and two-way audio
Thanks to Power over Ethernet (PoE), power and network connectivity can be achieved via a single network cable. This simplifies installation and makes the camera suitable for professional IP camera networks.
The built-in microphone and speakers also support two-way audio. This enables remote communication, for example at an entrance, gate, or other secured location.
Specifications
| Model | MS-C8164-FIPE |
| Camera | |
| Image Sensor | 1/2.8” 2 Megapixel progressive scan CMOS |
| Minimum Illumination | Color: 0.012Lux@F1.4 B/W: 0Lux with IR on |
| WDR | 120dB Super WDR |
| Shutter Time | 1/100000s-1s |
| IR Distance | Up to 50 m |
| Day/Night Mode | Day/Night/Auto/Customize/Schedule |
| S/N | >55dB |
| Lens | |
| Lens Type | Motorized 2.7-13.5mm@F1.4 |
| P-Iris | Yes |
| Field of View | H107°~H33°/D125°~D37° /V58°~V18° |
| Mount | Φ14 |
| Focus Control | Auto/Manual |
| Iris Control | Auto/Manual |
| Video | |
| Max. Image Resolution | 3840x2160 |
| Primary Stream | 60Hz: 30fps@(3840x2160, 3072x2048, 2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576) 50Hz: 25fps@(3840x2160, 3072x2048, 2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576) |
| Secondary Stream | 60Hz: 30fps@(704x576, 640x480, 640x360, 352x288, 320x240) 50Hz: 25fps@(704x576, 640x480, 640x360, 352x288, 320x240) |
| Tertiary Stream | 60Hz: 30fps@(1280x720, 704x576, 640x480, 640x360, 352x288, 320x240) 50Hz: 25fps@(1280x720, 704x576, 640x480, 640x360, 352x288, 320x240) |
| Video Compression | H.265+/H.265(HEVC)/H.264+/ H.264/MJPEG |
| Video Bit Rate | 16Kbps~16Mbps(CBR/VBR Adjustable) |
| Privacy Masking | Up to 24 areas |
| ROI | Up to 8 areas |
| Image Setting | Brightness/Contrast/ Saturation/Sharpness |
| Interface | |
| Ethernet | 1*RJ45 10M/100M Ethernet Port |
| Audio I/O | 1/1 (Multi-interfaceVersion) |
| Alarm I/O | 1/1 (Multi-interfaceVersion) |
| Network | |
| Network Storage | NAS(Support NFS, SMB/CIFS), ANR |
| Protocol | IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL |
| Audio | |
| Audio Compression | G.711/AAC/G.722/G.726 |
| Audio Sampling Rate | 8/16/32/48KHz |
| Audio Bit Rate | 16~256kbps |
| Two-way Audio | Support |
| Intelligent Analytics | |
| Video Analysis | Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed |
| Face Detection&Face Attribute Recognition |
Detect and capture faces,get real-time snapshots; The attributes include Age,Gender,Glasses,Mask and Cap; Support Faces Privacy Mode, the detected faces in the face detection area will be mosaic automatically. |
| People Counting&Report | Count the number of people entering or exiting, up to 4 detection areas for regional people counting |
| System | |
| Storage | Support microSD/SDHC/SDXC Card Local Storage, up to 1TB |
| Advanced Function | Heat Map, BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark |
| SIP/VoIP Support | Yes, Voice & Video-over-IP |
| Event Trigger | Motion Detection, Network Disconnection, External Input, Audio Alarm, etc |
| Event Action | FTP upload, SMTP upload, SD card recording, external output, SIP phone, HTTP notification, etc. |
| System Compatibility | ONVIF Profile G & Q & S & T, API |
| Operating Temperature | -40℃-60℃ |
| Operating Humidity | 0~95% (non-condensing) |
| Power Supply | PoE (802.3af) / DC 12V ± 10% |
| Power Consumption | 6W MAX 9W MAX (With IR on) |
| Housing | Vandal-proof metal casing with IK10 rating / Up to IP67 rating for weather-resistant performance |
| Weight | 825 grams |
| Dimensions | Φ76mmX239.5mm |
