Milesight MS-C5341-X30PC AI 30X Speed Dome 5MP
Product Description
The Milesight 30X High speed 5 Megapixel dome network IP camera is perfect for mass CCTV deployment. Powered by an advanced AI engine, Milesight's new generation video analytics provides higher accuracy with a pre-trained deep learning model and continuously learns automatically new algorithms. Milesight cameras can intelligently filter objects to focus on detecting people and vehicles, this function combined with multiple event rules (including region entry, object removed, loitering, etc.) ensures access to various implementations, enabling a smarter and safer world.
Intelligent face recognition takes security surveillance to a new level. Milesights Artificial Intelligence IP Camera Series detects human faces in the surveillance scene and captures the snapshots. This function greatly improves the surveillance efficiency by capturing useful facial information. With the snapshots, the people in question can be quickly located, which is beneficial to major population-related industries such as public security, access control and enterprise management.
The advanced pan/tilt mechanism provides fast, precise movement with endless 360° pan and 90° tilt. The user can easily control the lens position via the mouse to monitor the area of interest and set up to 255 preset positions for patrolling. With the PTZ auto tracking and motion detection enabled, the camera will track the target and zoom in whenever it can to intelligently capture anyone or anything moving in the camera’s patrol path. Once the relevant information is captured and the target has moved on, the camera will automatically resume normal patrol.
Specifications
Objective |
AF Motor 30xZOOM 4.7∼141mm lens, H62°∼H3°/D70°∼D3°/V37°∼V1° (Wide-Tele), Auto Shutter Auto/Manual Focus High Speed ZOOM 3.1s |
Image sensor | Starlight, CMOS SONY 1/2.8" progressive scan |
Min. lighting | Color: 0.005Lux @F1.2, B/W: 0Lux with IR on |
WDR (wide dynamic range) | WDR Ultra (120dB) |
Cut-off time | 1/100000s ∼1s |
IR distance |
SMART 3G IR 200m with automatic ZOOM Intensity |
Max. resolution | 2592x1944/30fps |
Frame rate |
Chef Stream 30fps@ (2592x1944), 60fps@ (1920x1080, 1280x960, 1280x720, 704x576) Minor Stream 60fps@ (704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x176) Third Stream 30fps@ (1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x176) |
Video compression | H.265+/H.265 (HEVC)/H.264+/H.264/MJPEG |
Video Bitrate | 16Kbps ~ 16Mbps (CBR/VBR adjustable) |
PTZ parameters |
Horizontal movement PAN 360° speed 0.5°∼180°/s, preset speed: 240°/s Vertical movement TILT -5°∼90° speed: 0.5°∼120°/s, preset speed: 200°/s Proportional ZOOM 255 Presets 8 "Patrol" detours and up to 48 patrol presets 4 Templates Support Freezing Temporary Support Shut Down Memory PTZ screen position in the image with the option to turn it off 3D Control Position Position |
Audio |
External input and output G.711/AAC audio compression |
Multi I/O port | YES, AUDIO, 2x ALARM input and output, RS485, 24VAC power supply |
Image settings | Saturation/Brightness/Contrast/Sharpness |
Web-based access | IE/Firefox/Chrome/Safari browser |
Ethernet | 1 x 10/100 Mbps |
Network protocols | IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, ARP |
Intelligent video | Motion Detection, Protective Mask, Backlight Compensation, 3D Noise Reduction, ROI |
SIP/VoIP support | YES, Voice&Video-over-IP |
Video analysis (VCA) |
10 Detection Features Included: Zone entry detection Zone Exit Detection Advanced motion detection Detecting sabotage with the camera Line crossing detection Detection of suspicious movements in the zone Person detection People counting Loss of object Snooze an object |
Trigger an event | VCA, motion detection, network connection, audio, sabotage alarm Unauthorized intrusion |
Event promotions | FTP / SMTP / SD card / SIP phone |
Time-lapse function |
YES, periodically stores images from the camera to FTP or SD Tab at a set interval |
System Compatibility | ONVIF Profile S&G& T |
Anti-vandalism certification | IK10 |
IP protection | IP66 |
Operating Temperature | -40°C - 60°C |
Operating humidity | 0-90% (non-condensing) |
Feed |
PoE (802.3af) / AC 24V/3A ±10% 6KV surge protection |
Consumption | 13W MAX / 25W MAX (with IR activated) |
Dimensions | Φ205mm x 308mm |
Weight | 4000g |
