Milesight MS-C8241-X36PC 36X AI Speed Dome 4K
Regular price
€2.080,00
Tax included.
Shipping calculated at checkout.
Product Description
Get 360° surveillance, day and night, with this 8MP speed network dome camera accompanied by an astonishing 36x optical zoom. Featuring a built-in AI engine that analyzes video content for rapid event response, 140dB Super WDR pro for incredible image quality, and Smart IR II for super-detailed images with up to 300m coverage in nighttime conditions.
This camera performs ultra-fast and accurate automatic PTZ tracking with 3D positioning and intelligent motion detection.
It is an intelligent solution that improves and accelerates security management decision-making, resulting in greater operational efficiency.
Big sensor, high speed, huge benefits.
Specifications
| Sensor resolution | 8 megapixel |
| Camera image sensor | 1/1.8" Progressive Scan CMOS |
| Minimum lighting | B/W: 0Lux with IR on Color: 0.006Lux @F1.2 Color: 0.009Lux @F1.55 |
| Wide Dynamic Range (WDR) | 120dB SuperWDR |
| Shutter speed | 1/100,000s∼1s |
| Day/Night Mode | Day/Night/Auto/Customize/Schedule |
| IR distance | Up to 300 meters |
| Digital magnification | 16X |
| Signal to Noise Ratio (S/N) | Greater than 55 dB |
| Focal length | 5.7∼205.2mm, 36x optical zoom |
| Zoom speed | About 7s (wide angle) |
| Lens field of view | H66°∼H3°/D72°∼D3°/V41°∼V1° |
| Focus control | Automatic Manually Semi-automatic |
| Minimum working distance lens | 1500/1500 mm (wide/telephoto) |
| Lens aperture | F1.55∼F4.8 |
| Lens iris adjustment | Auto |
| Video Maximum image resolution | 3840x2160 |
| Primary video stream | 50 Hz: 25 fps @ (3840 x 2160, 3072 x 2048, 2592 x 1944, 2592 x 1520, 2048 x 1536, 1920 x 1080, 1280 x 960, 1280 x 720, 704 x 576) 60 Hz: 30 fps @ (3840 x2160, 3072x2048, 2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576) |
| Video secondary stream | 50Hz: 25fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180) 60Hz: 30fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180) |
| Video Tertiary stream | 50Hz: 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x180) 60Hz: 30fps@(1920x1080, 1280x720, 704 x576, 640x480, 640x360, 320x240, 320x192, 320x180) |
| Video compression | H.264 H.264+ H.265(HEVC) H.265+ MJPEG |
| Video bit rate | 16Kbps∼16Mbps (CBR/VBR adjustable) |
| Video Privacy Masking | Maximum 28 areas (24 mask areas and 4 mosaic areas) |
| Area of Interest (ROI) | Maximum 8 areas |
| Video image settings | Brightness Contrast Saturation Sharpness |
| Video web access | Support IE/Firefox/Chrome/Safari browser |
| Audio compression | AAC G.711 G.722 G.726 |
| Audio sampling rate | 8/16/32/44.1/48 KHz |
| Audio bit rate | 16~256 kbps |
| Two-way audio | Supported |
| Intelligent video analysis | Advanced motion detection Line Crossing Hanging object Left object deleted Region entrance Region exit Sabotage detection |
| Ethernet interface | 1*RJ45 10M/100M Ethernet port |
| Network protocols | IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, Bonjour, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL |
| Power input | 802.3 at PoE AC 24V/3A ±10% |
| Energy consumption | 13W MAX 25W MAX (with IR on) |
| Dimensions of the housing | Φ205mmX308mm |
| Weight | 4 kg |
| Housing | Vandal-resistant metal housing with IK10 rating |
| Heating | Support |
| Weatherproof | Up to IP66 rated for weatherproof performance |
| Surge protection | 6KV |
| Operating temperature range | -40ºC to +60ºC |
| Operating range relative humidity | 0% to 90% (non-condensing) |
| Audio I/O | 1/1 |
| Alarm I/O | 4/2 |
| Network storage | ANR NAS (NFS, SMB/CIFS support) |
| System storage | Support microSD/SDHC/SDXC card local storage, up to 256G |
| System advanced function | BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, EIS, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Blur, Watermark |
| SIP/VoIP support | Yes, Voice&Video-over-IP |
| Event trigger | Motion detection, network connection, external input, audio alarm, etc. |
| Event Action | FTP upload, SMTP upload, SD card recording, external output, SIP phone, PTZ movement, HTTP notification, etc. |
| System Compatibility | ONVIF profile G & Q & S & T, API |
| PTZ Pan Range/Pan Speed | 360° endless/ pan Manual speed: 0.1°∼250°/s, pan preset speed: 250°/s |
| PTZ Tilt Range/Tilt Speed | -5°∼90°(Auto Flip)/ Tilt Manual speed: 0.5°∼160°/s, Preset tilt speed: 160°/s |
| PTZ proportional zoom | Support |
| Number of PTZ presets | 300 |
| PTZ patrol | 8 patrols, maximum 48 presets per patrol |
| PTZ pattern | 4 Patterns |
| PTZ auto follow | Support |
| PTZ power off memory | Support |
| PTZ Other function | 3D positioning Auto Home Auto Scan Starting position PTZ limits Freeze preset |
| IR irradiation angle | Automatic/Manual |
| Intelligent face detection | Detect and capture faces, get real-time snapshots |
| Counting and reporting people | Count the number of people entering or leaving, up to 4 detection areas for regional people counting |
| Interface RS485 | Support |
