Ajax StreetSiren DoubleDeck Wireless
Product Description
StreetSiren DoubleDeck is a wireless outdoor siren with brand plate holder. Equipped with an LED frame and piezoelectric alarm indicator that produces a sound volume of up to 113 dB, StreetSiren can operate for up to 5 years with pre-installed batteries. It can also be powered by an external 12 V power supply.
StreetSiren DoubleDeck communicates with the hub via the secure Jeweller radio protocol. The communication range is up to 1,500 meters provided there are no obstacles.
More features
The StreetSiren DoubleDeck performs two tasks:
1. Informs about the alarm . The device responds to the activation of the tamper and security system alarms in less than a second, including a siren and LED backlight, which scares off intruders and attracts the attention of neighbors.
2. Serves as a security status indicator . The siren uses LED indication to report that the object is armed, as well as sound and LEDs to warn about the delay in entering / exiting. These functions are useful when operating the security system with SpaceControl or KeyPad (the siren reminds you to disarm when you enter the object).
When installed correctly, it is difficult to disassemble and disconnect an activated siren: the casing is robust, the buzzer is protected and the power comes from the batteries provided, so the siren continues to work even if there is a power failure at the object. When the system is armed, the on/off button is blocked, preventing the siren from being turned off.
The siren is equipped with a tamper button and an accelerometer. The tamper button is activated when the device's housing is opened/broken and the accelerometer is activated when someone tries to move or disassemble the device.
Specifications
| Siren type | Wireless |
| Type of notification | Sound and light |
| Installation method | Inside / Outside |
| Brandplate material | Plastic |
| Fire plate installation method | Clip lock and mounting screw |
| Notification volume | 85–113 dB at a distance of 1 m (adjustable) |
| Alarm sounding time | Adjustable, 3 to 180 seconds |
| Siren sound warning frequency | 3.5 ± 0.5 kHz |
| Protection against dismantling | Accelerometer and sabotage for violation of body integrity |
| Compatibility | Only works with all Ajax hubs and radio signal range extenders |
| Switch status indication on/off | Available |
| Indication of delays at entry/exit | Available |
| Radio communication protocol | Jeweler More information |
| Radio frequency band | 866.0 – 866.5 MHz 868.0 – 868.6 MHz 868.7 – 869.2 MHz 905.0 – 926.5 MHz 915.85 – 926.5 MHz 921.0 – 922.0 MHz Depending on the region of sale. |
| Maximum RF output power | 7.29 mW (max 25 mW) |
| Range of radio signals | Up to 1,500 m (no obstacles) More information |
| Power supply | 4 × CR123A, 3V |
| Battery life | Up to 5 years More information |
| Auxiliary power supply | 12 V DC, 1.5 A |
| Level of protection for the body | IP55 |
| Operating temperature range | From –25°С to +50°С |
| Operating humidity | Up to 95% |
| Dimensions | 200 × 200 × 55 mm |
| Weight | 571 gr |
| Lifespan | 10 years |
