UNIView 9-Channel High Definition Video Decoder (ADU8709-E-V3)
Regular price
€4.575,00
Tax included.
Shipping calculated at checkout.
Product Description
The decoder can be used in a variety of scenarios, but a popular way to use the HD video decoder is to create a video wall. This solution is beneficial for a security office and is a simple and robust solution that works with your existing Uniview system .
The Uniview HD Video Decoder can be set up using Uniview's free EZWALL software. This Uniview software runs on your Windows PC connected directly to the decoder or on the same network as the decoder. The EZWALL software's user interface allows you to create various custom layouts.
The EZWALL application is used for configuration only. This application pushes all settings to the decoder, where they are hosted/stored.
Specifications
| Model | ADU8709-E-V3 |
| Input | 4-channel HDMI (video only) |
| HDMI input resolution | 4K interface: 3840*2160(4K)@30Hz, 1920*1080(1080P)@60Hz, 1920*1080(1080P)@50Hz, 1920*1080(1080P)@30Hz, 1600*1200(UXGA)@60Hz, 1440*900(WXGA)@60Hz, 1280*1024(SXGA)@60Hz, 1280*720(720P)@60Hz, 1280*720(720P)@50Hz, 1024*768(XGA)@60Hz(4K interface: 1, 2) 1080P interface：1920*1080(1080P)@60Hz, 1920*1080(1080P)@50Hz, 1920*1080（1080P）@30Hz, 1600*1200(UXGA)@60Hz, 1440*900(WXGA)@60Hz, 1280*1024(SXGA)@60Hz, 1280*720(720P)@60Hz, 1280*720(720P)@50Hz, 1024*768(XGA)@60Hz(1080P interface：3, 4) |
| Output | 9-channel HDMI |
| HDMI output resolution | 4K Interface: 3840*2160(4K)@30Hz, 1920*1200(WUXGA)@60Hz, 1920*1080(1080P)@60Hz, 1600*1200(UXGA)@60Hz, 1440*900(WXGA+ ) @ 60Hz, 1280*1024 (SXGA) @ 60Hz, 1280*720 (720P) @ 60Hz, 1024*768 (XGA) @ 60Hz (4K interface: 1, 2, 4, 5, 7, 8 , 10, 11) 1080P interface: 1920*1200(WUXGA)@60Hz, 1920*1080(1080P)@60Hz, 1600*1200(UXGA)@60Hz, 1440*900(WXGA+)@60Hz, 1280*1024(SXGA)@60Hz, 1280*720(720P)@60Hz, 1024*768(XGA)@60Hz(1080P interface: 3, 6, 9, 12) |
| Decoding format | H.265, H.264, MPEG4 |
| Decoding power | 12*12MP@20Hz 12*4K@30Hz 48*1080P@30Hz 108*720P@30Hz |
| Split | M*N (the number of windows cannot exceed the number of output channels) |
| windows | 36* number of output channels |
| Audio input | 1 * audio input (reserved) 1 * 3.5mm audio input (reserved) |
| Audio output | 1 * audio output (reserved) 1 * 3.5mm audio output, dual channel |
| Alarm input | 4 * terminal alarm input (reserved) |
| Alarm output | 4 * terminal alarm output (reserved) |
| Serial port | 1*RS232, 1*RS485 |
| Ethernet | 2 * GE port, RJ45 interface, half-duplex/full-duplex Ethernet, 10M/100M/1000M Base-T adaptive |
| USB | 2 * USB3.0 |
| Dimensions (W*H*D)(mm) | 440 * 44 * 339 |
| Weight (kg) | 3.9 |
| Maximum power consumption (W) | 40 |
| Power supply | 100V to 240V AC; 50Hz/60Hz |
| Operating temperature | -10°C to 55°C |
| Control humidity | 10% to 90% RH, non-condensing |
