UNIView 6-channel High Definition Video Decoder (ADU8706-E-V3)
Product Description
The ADU8706-E-V3 is a professional video decoder from UNIVIEW. This decoder is the perfect solution for creating a video wall. Using a decoder ensures minimal network load and prevents a computer from having to process the images on multiple screens. The ADU8706-E-V3 has 6 HDMI outputs for displaying images. There are also 4 HDMI inputs for connecting image sources such as a computer or recorder.
The video wall is set up with the EZstation software or by means of the EZwall software. After setting up the video wall, the software can be closed and the decoder will continue to function. The decoder retrieves video streams directly from recorders and is equipped with 2 network ports for load balancing.
It is possible to connect a PTZ keyboard to this decoder for easy operation of PTZ cameras.
Specifications
| Model | ADU8706-E-V3 |
| Input | 4-channel HDMI (video only) |
| HDMI Input Resolution |
4K interface: 3840 * 2160 (4K) @30Hz, 1920 * 1080 (1080P) @60Hz, 1920 * 1080 (1080P) @50Hz, 1920 * 1080 (1080P) @30Hz, 1600 * 1200 (UXGA) @60Hz, 1440 * 900 (WXGA) @60Hz, 1280 * 1024 (SXGA) @60Hz, 1280 * 720 (720P) @60Hz, 1280 * 720 (720P) @50Hz, 1024 * 768 (XGA) @60Hz (4K- interface: 1, 2) 1080P interface: 1920*1080 (1080P) @60Hz, 1920*1080 (1080P) @50Hz, 1920*1080 (1080P) @30Hz, 1600*1200 (UXGA) @60Hz, 1440*900 (WXGA) @60Hz, 1280*1024 (SXGA) @60Hz, 1280*720 (720P) @60Hz, 1280*720 (720P) @50Hz, 1024*768 (XGA)@60Hz (1080P interface: 3, 4) |
| Windows | 6-channel HDMI |
| HDMI output resolution |
4K interface: 3840 * 2160 (4K) @30Hz, 1920 * 1200 (WUXGA) @60Hz, 1920 * 1080 (1080P) @60Hz, 1600 * 1200 (UXGA) @60Hz, 1440 * 900 (WXGA+) @60Hz, 1280 * 1024 (SXGA) @60Hz, 1280 * 720 (720P) @60Hz, 1024 * 768 (XGA) @60Hz (4K interface: 1, 2, 4, 5, 7, 8, 10, 11) 1080P interface: 1920*1200 (WUXGA) @60Hz, 1920*1080 (1080P) @60Hz, 1600*1200 (UXGA) @60Hz, 1440*900 (WXGA+) @60Hz, 1280*1024 (SXGA) @60Hz, 1280*720 (720P) @60Hz, 1024*768 (XGA) @60Hz (1080P interface: 3, 6, 9, 12) |
| Decode format | H.265, H.264, MPEG4 |
| Possibility of decoding |
8*12MP@20Hz 8*4K@30Hz 32*1080P@30Hz 72*720P@30Hz |
| Splicing | M*N (the number of windows cannot exceed the number of output channels) |
| Windows | 36* number of output channels |
| Audio input |
1 * Terminal audio input (reserved) 1 * 3.5mm audio input (reserved) |
| Audio output |
1 * Terminal audio output (reserved) 1 * 3.5mm audio output, dual channel |
| Alarm input | 4 * Terminal alarm input (reserved) |
| Alarm output | 4 * Terminal alarm output (reserved) |
| Serial port | 1*RS232, 1*RS485 |
| Ethernet | 2 * GE port, RJ45 interface, half-duplex/full-duplex Ethernet, 10M/100M/1000M Base-T adaptive |
| USB | 2 * USB3.0 |
| Dimensions (W * H * D (mm) | 440 * 44 * 339 |
| Weight (kg) | 3.83 |
| Max. power consumption (W) | 32 |
| Power supply | 100V to 240V AC; 50Hz/60Hz |
| Operating temperature | -10°C to 55°C |
| Operating humidity | 10% to 90% RH, non-condensing |
